2.00mm (.079″) Board to Board Connector

Specification

Measurement2.00mm (.079")
Circuits1~40 circuits
Current Rating2A AC DC
Voltage Rating250V AC DC
Temperature rating:-40℃~+105℃
Contact resistance20mΩ max.
Insulation resistance1000MΩ min.
Withstanding voltage500V AC/min.

Standards

Product Details

  • 2006 Series 2.00mm (.097") Single Row Breakaway Header
Product2006P
Circuits1~40 circuits
MaterialNylon 6T UL94V-0/Brass
Material Options-
Color Options-
FormulaP/N 2006P***L**
Options-
Other InformatonMates with 2.00mm(.079")socket
