1.25mm(.049″) Wire to Board Connector

Specification

Measurement1.25mm (.049")
Circuits10,20,30,40 circuits
Current Rating1A AC DC
Voltage Rating125V AC DC
Temperature rating:-25℃~+85℃
Contact resistance30mΩ max.
Insulation resistance100MΩ min.
Withstanding voltage500V AC/min.

Standards

Product Details

  • 1262 Series 1.25mm (.049") Dual Row Housing
  • 1262 Series 1.25mm (.049") Dual Row Header
  • 1621T Crimping Terminal
Product1262S
Circuits10,20,30,40 circuits
MaterialPolyester UL94V-0
Material Options-
Color Options-
FormulaP/N 1262S**0000
Options-
Other InformatonMates with 1262P
Product1262P
Circuits10,20,30,40 circuits
MaterialHigh Temperature Thermoplastic UL94V-0/Copper Alloy
Material Options-
Color Options-
FormulaP/N 1262P**00*B
Options-
Other InformatonMates with 1261 Terminal
Product1261T
Circuits-
MaterialPhosphor Bronze
Material Options-
Color Options-
FormulaP/N 1261TPB0000
Options-
Other InformatonMates with 1262S AWG 26~30 Tin plated 15K Pcs/Reel
