Telephone Jack (PCB Mount)

//Telephone Jack (PCB Mount)

Telephone Jack (PCB Mount)

Specification

Measurement1.27mm(.050")*2.54mm(.100")
Circuits-
Current Rating1.5A AC DC
Voltage Rating125V AC DC
Temperature rating:-25℃~+105℃
Contact resistance20mΩ max.
Insulation resistance1000MΩ min.
Withstanding voltage1000V AC/min.

Standards

Product Details

  • 7625 Series PCB Mount Telephone Jack Top Entry Type
  • 7625 Series PCB Mount Telephone Jack Top Entry Type
  • 7625 Series PCB Mount Telephone Jack Top Entry Type
Product7625
Circuits-
MaterialPolyester UL94V-0/Phosphor Bronze
Material Options-
Color Options-
FormulaP/N 7625-0404**
Options-
Other Informaton-
Product7625
Circuits-
MaterialPolyester UL94V-0/Phosphor Bronze
Material Options-
Color Options--
FormulaP/N 7625-0606**
Options-
Other Informaton-
Product7625
Circuits-
MaterialPolyester UL94V-0/Phosphor Bronze
Material Options-
Color Options-
FormulaP/N 7625-0808**
Options-
Other Informaton-
