2.54mm (.100″) Board to Board Connector

Specification

Measurement2.54mm (.100")
Circuits1-40circuits
Current Rating3A AC DC
Voltage Rating250V AC DC
Temperature rating:-40℃~+105℃
Contact resistance20mΩ max.
Insulation resistance1000MΩ min.
Withstanding voltage1000V AC/min.

Standards

Product Details

  • 2567 Series 2.54mm (.100") Single Row Breakaway Right Angel Header
  • 2567 Series 2.54mm (.100") SMT Header
Product2567P
Circuits1-40 circuits
MaterialNylon 6T UL94V-0
Material Options-
Color Options-
FormulaP/N 2567P******
Options-
Other InformatonMates with 2.54mm(.100")socket
Product2567P
Circuits2-40 circuits
MaterialHigh temperature thermoplastic UL 94V-0/Brass
Material Options-
Color Options-
FormulaP/N 2567P**TMA7
Options-
Other InformatonMates with 2.54mm(.100")socket
